SOLAR CHG CTRL 12/24V 20A IP67 W/TIMER

Product Overview

A highly efficient, fully automatic 12/24V PWM solar charge controller designed to enhance battery life and optimize solar system performance. This controller utilises advanced digital technology and features a robust industrial housing with IP67 protection, making it ideal for extreme outdoor environments prone to corrosion, dust, and water ingress.

The controller automatically detects day/night cycles and includes an inbuilt timer that allows you to set operational intervals or manually control loads during nighttime.

Key Features:

• High efficient PWM charging
• Automatically recognises day/night
• LED indicators for PV and battery status
• Intelligent timer function with 1 to 13 hours option
• PV reverse polarity protection
• Battery protections: overcharge, over discharge, reverse polarity, and overheating
• Load protections: overload and short circuit
• Voltage: 12/24VDC Automatic
• IP Rating: IP67

Specifications:

• DC Current Rating: 20A
• DC Voltage: 12V, 24V
• IP Rating: IP67
  • Dust/Particle Ingress Protection: 6 - Dust tight, no ingress of dust
  • Liquid/Moisture Ingress Protection: 7 - Immersion up to 1m
• Operating Temperature: -35°C to 55°C
• Input Type: Flyleads
• Output Type: Flyleads

Dimensions:

• Length: 109mm
• Width: 75mm
• Height: 26mm
• Weight: 435g

Packaging:

• Packaged Volume: 0.71l
• Packaged Weight: 0.38kg
• Packaged Length: 12.5cm
• Packaged Width: 11.6cm
• Packaged Height: 4.9cm

Performance:

• Charge Controller Technology: Pulse Width Modulated (PWM)
• Max PV Open Circuit Voltage: 50V
• Max Charging Current: 20A
• Max Load Current: 20A
• Max Solar Panel Array: 240W, 480W

This solar charge controller is the perfect solution for maintaining the efficiency and longevity of your solar system, especially in challenging outdoor conditions.
