SZ1907 6 Way IP66 Marine Switch Panel

Premium Marine-Style Rocker Switch Panel

Designed with the same tactile rocker switches found on high-end Australian and international motor cruisers, this switch panel combines style, durability, and practicality. Each unit comes pre-wired for convenience, with all connections made via standard spade terminals for quick installation.

Key Features:

• Pre-wired for convenience: Standard spade terminals ensure quick and easy installation.
• Built-in circuit breakers: Ratings include 6A, 10A, 15A, and 20A for reliable protection.
• LED-illuminated switches: Provides clear visual indication of active circuits, even in low light.
• Durable ABS plastic construction: Offers a clean, modern finish that is both attractive and long-lasting.

The panel requires approximately 80mm of clearance behind the mounting surface, making it suitable for a variety of installations. Its robust design and high-quality materials make it ideal for marine or automotive applications, where both performance and appearance are essential.

Also available:
SZ1906 - 4 Way IP66 Marine Switch Panel

Specifications

• DC Voltage: 12V, 24V
• IP Rating: IP66 (certificate included)
• Dimensions:
  • Length: 170mm
  • Width: 130mm
• Packaged Details:
  • Volume: 5.09L
  • Weight: 0.57kg
  • Length: 26.9cm
  • Width: 16.6cm
  • Height: 11.4cm
• Switch Type: Rocker
  • Throws/Positions: 1 position
  • Connection: Spade Terminals
  • Colour: Black
• Material: ABS Plastic (Acrylonitrile Butadiene Styrene)
• Number of Switches: 6 pieces
• Individual Circuit Breakers: 6A, 20A

This SZ1907 6 Way IP66 Marine Switch Panel is the perfect solution for those seeking a reliable and stylish switch panel for marine or automotive use.
